Valve Info - , HP

Pressure Ratings

Series 20 High Pressure Impact Valves 2 Way Normally Open Explosion Proof - Model EH21 Click here for specs GAS Pressure Rating Orifice Size CV Factor Valve Number LIQUID Pressure Rating Orifice Size CV Factor Valve Number 3000 1/32 .022 EH21G7DCCM 3000 1/32 .022 EH21G7DCCM 2500 3/64 .041 EH21H7DCCMG 1500 3/64 .041 EH21H7DCCML 1350 1/16 .061 EH21J7DCCMG 850 1/16 .061 EH21J7DCCML 450 3/34 .084 EH21K7DCCMG 300 3/32 .084 EH21K7DCCML Series 20 High Pressure Explosion Proof Impact Valves 2 Way Normally Closed 1/4 NPT Stainless Steel - Model EH22 Click here for specs PSI Ratings Gas Orifice Size CV Factor Explosion Proof 1/4 NPT AC DC 3000 3000 1/32 .022 EH22G9DCCM 2500 1500 3/64 .041 EH22H9DCCMG 1750 500 1/16 .065 EH22J9DCCMG 650 100 3/32 .100 EH22K9DCCMG PSI Ratings Liquid Orifice Size CV Factor Explosion Proof 1/4 NPT AC DC 3000 3000 1/32 .022 EH22G9DCCM 1500 1500 3/64 .041 EH22H9DCCML 1000 500 1/16 .065 EH22J9DCCML 300 100 3/32 .100 EH22K9DCCML Series 20 High Pressure Explosion Proof Impact Valves 2 Way Normally Closed 1/8 NPT Stainless Steel - Model EH22 Click here for specs PSI Ratings Gas Orifice Size CV Factor Explosion Proof 1/8 NPT AC DC 3000 3000 1/32 .022 EH22G7DCCM 2500 1500 3/64 .041 EH22H7DCCMG 1750 500 1/16 .065 EH22J7DCCMG 650 100 3/32 .100 EH22K7DCCMG PSI Ratings Liquid Orifice Size CV Factor Explosion Proof 1/8 NPT AC DC 3000 3000 1/32 .022 EH22G7DCCM 1500 1500 3/64 .041 EH22H7DCCML 1000 500 1/16 .065 EH22J7DCCML 300 100 3/32 .100 EH22K7DCCML SERIES 20 High Pressure Explosion Proof Impact Valves 3 Way Normally Closed - Stainless Steel - 1/4 NPT - Model EH23 Click here for specs PSI Ratings Gas Orifice Size CV Factor Explosion Proof AC DC 3000 3000 1/32 .022 EH23GG19DCCM 2500 1500 3/64 .041 EH23HH19DCCMG 1750 500 1/16 .065 EH23JJ19DCCMG 650 100 3/32 .100 EH23KK19DCCMG PSI Ratings Liquid Orifice Size CV Factor Explosion Proof AC DC 3000 3000 1/32 .022 EH23GG19DCCML 1500 1500 3/64 .050 EH23HH19DCCML 1000 500 1/16 .070 EH23JJ19DCCML 300 100 3/32 .130 EH23KK19DCCML Series 20 High Pressure Impact Valves 2 Way Normally Closed 1/4 NPT Stainless Steel - Model H22 Click here for specs PSI Ratings Gas Orifice Size CV Factor Grommet 1/4 NPT Conduit 1/4 NPT AC DC 3000 3000 1/32 .022 H22G9DGV H22G9DCV 2500 1500 3/64 .041 H22H9DGVG H22H9DCVG 1750 500 1/16 .065 H22J9DGVG H22J9DCVG 650 100 3/32 .100 H22K9DGVG H22K9DCVG PSI Ratings Liquid Orifice Size CV Factor Grommet 1/4 NPT Conduit 1/4 NPT AC DC 3000 3000 1/32 .022 H22G9DGV H22G9DCV 1500 1500 3/64 .041 H22H9DGVL H22H9DCVL 1000 500 1/16 .065 H22J9DGVL H22J9DCVL 300 100 3/32 .100 H22K9DGVL H22K9DCVL Series 20 High Pressure Impact Valves 2 Way Normally Closed 1/8 NPT Stainless Steel - Model H22 Click here for specs PSI Ratings Gas Orifice Size CV Factor Grommet 1/8 NPT Conduit 1/8 NPT AC DC 3000 3000 1/32 .022 H22G7DGV H22G7DCV 2500 1500 3/64 .041 H22H7DGVG H22H7DCVG 1750 500 1/16 .065 H22J7DGVG H22J7DCVG 650 100 3/32 .100 H22K7DGVG H22K7DCVG PSI Ratings Liquid Orifice Size CV Factor Grommet 1/8 NPT Conduit 1/8 NPT AC DC 3000 3000 1/32 .022 H22G7DGV H22G7DCV 1500 1500 3/64 .041 H22H7DGVL H22H7DCVL 1000 500 1/16 .065 H22J7DGVL H22J7DCVL 300 100 3/32 .100 H22K7DGVL H22K7DCVL SERIES 20 High Pressure Impact Valves 3 Way Normally Closed - Stainless Steel - 1/4 NPT - Model H23 Click here for specs PSI Ratings Gas Orifice Size CV Factor Conduit AC DC 3000 3000 1/32 .022 H23GG19DCV 2500 1500 3/64 .041 H23HH19DCVG 1750 500 1/16 .065 H23JJ19DCMG 650 100 3/32 .100 H23KK19DCMG PSI Ratings Liquid Orifice Size CV Factor Conduit AC DC 3000 3000 1/32 .022 H23GG19DGVL 1500 1500 3/64 .050 H23HH19DCVL 1000 500 1/16 .070 H23JJ19DCVL 300 100 3/32 .130 H23KK19DCVL
