Valve Info - , EP

Pressure Ratings

Series 20 - Stainless Steel 2 Way Normally Open Explosion Proof - Model E21 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC Inlet Exh Inlet Exh CONDUIT HOUSING 1/8" NPT CONDUIT HOUSING 1/4" NPT 400 (700) 400 (700) 1/32 .024 E21G7XCCM E21G9ZCCM 235 (500) 235 (500) 3/64 .053 E21H7XCCM E21H9ZCCM 150 (350) 150 (350) 1/16 .095 E21J7XCCM E21J9ZCCM 100 (150) 100 (150) 3/32 .156 E21K7XCCM E21K9ZCCM Series 20 - Stainless Steel 2 Way Normally Closed - Explosion Proof - Model E22 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC Inlet Exh Inlet Exh CONDUIT HOUSING 1/8" NPT CONDUIT HOUSING 1/4" NPT 500 500 1/32 .024 E22G7DCCM E22G9DCCM 250(500) 250(500) 3/64 .052 E22H7DCCM E22H9DCCM 200(400) 200(400) 1/16 .095 E22J7DCCM E22J9DCCM 125(300) 125(250) 3/32 .156 E22K7DCCM E22K9DCCM 100(200) 100(200) 1/8 .214 E22N7DCCM E22N9DCCM 75 50 5/32 .404 E22O7DCCM E22O9DCCM 50 25 3/16 .500 E22P7DCCM E22P9DCCM 20 5 1/4 .700 E22R7DCCM E22R9DCCM Series 20 - Stainless Steel 3 Way Normally Closed Piped Exhaust - Explosion Proof - Model E23 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC CONDUIT HOUSING (1/2" NPT) 1/8 NPT Ports 1/4 NPT Ports 400 400 1/32 1/32 .024 .024 E23GG7XCCM E23GG9ZCCM 150 (200) 150 (200) 3/64 1/16 .052 .095 E23HJ7XCCM E23HJ9ZCCM 100 (135) 100 (135) 1/16 1/16 .095 .095 E23JJ7XCCM E23JJ9ZCCM 100 (135) 100 (135) 1/16 3/32 .095 .156 E23JK7XCCM E23JK9ZCCM 75 (100) 75 (100) 3/32 3/32 .156 .156 E23KK7XCCM E23KK9ZCCM 50 (70) 50 (70) 1/8 3/32 .214 .156 E23NK7XCCM E23NK9ZCCM 20 20 3/16 3/32 .500 .156 E23PK7XCCM E23PK9ZCCM 15 - 1/4 3/32 .700 .156 E23RK7XCCM E23RK9ZCCM Series 20 - Stainless Steel 3 Way Normally Closed Exhaust to Atmosphere-Explosion Proof-Model E23 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC CONDUIT HOUSING (1/2" NPT) 1/8 NPT Ports 1/4 NPT Ports 400 400 1/32 1/32 .024 .024 E23GG7DCCM E23GG9DCCM 150 (200) 150 (200) 3/64 1/16 .052 .095 E23HJ7DCCM E23HJ9DCCM 100 (135) 100 (135) 1/16 1/16 .095 .095 E23JJ7DCCM E23JJ9DCCM 100 (135) 100 (135) 1/16 3/32 .095 .156 E23JK7DCCM E23JK9DCCM 75 (100) 75 (100) 3/32 3/32 .156 .156 E23KK7DCCM E23KK9DCCM 50 (70) 50 (70) 1/8 3/32 .214 .156 E23NK7DCCM E23NK9DCCM 20 20 3/16 3/32 .500 .156 E23PK7DCCM E23PK9DCCM 15 - 1/4 3/32 .700 .156 E23RK7DCCM E23RK9DCCM Series 20 - Stainless Steel 3 Way Normally Open - Explosion Proof - Model E24 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC CONDUIT HOUSING (1/2" NPT) 1/8 NPT Ports 1/4 NPT Ports 400 400 1/32 1/32 .024 .024 E24GG7XCCM E24GG9ZCCM 150 (225) 150 3/64 1/16 .052 .095 E24HJ7XCCM E24HJ9ZCCM 100 (150) 100 1/16 1/16 .095 .095 E24JJ7XCCM E24JJ9ZCCM 100 (125) 100 1/16 1/8 .095 .214 E24JN7XCCM E24JN9ZCCM 75 (90) 75 3/32 1/8 .156 .214 E24KN7XCCM E24KN9ZCCM Series 20 - Stainless Steel 3 Way Directional Control - Explosion Proof - Model E25 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC CONDUIT HOUSING (1/2" NPT) 1/8 NPT Ports 1/4 NPT Ports 500 500 1/32 1/32 .024 .024 E25GG7XCCM E25GG9ZCCM 235 (400) 235 (300) 3/64 3/64 .052 .052 E25HH7XCCM E25HH9ZCCM 200 (225) 200 (200) 1/16 3/64 .095 .052 E25JH7XCCM E25JH9ZCCM 150 (225) 150 (200) 1/16 1/16 .095 .095 E25JJ7XCCM E25JJ9ZCCM 100 (150) 100 (125) 3/32 3/32 .156 .156 E25KK7XCCM E25KK9ZCCM 100 (125) 100 1/8 3/32 .214 .156 E25NK7XCCM E25NK9ZCCM Series 20 - Stainless Steel 3 Way Multi Purpose - Explosion Proof - Model E26 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC CONDUIT HOUSING (1/2" NPT) 1/8 NPT Ports 1/4 NPT Ports 400 400 1/32 1/32 .024 .024 E26GG7XCCM E26GG9ZCCM 150 150 3/64 3/64 .052 .052 E26HH7XCCM E26HH9ZCCM 100 100 1/16 1/16 .095 .095 E26JJ7XCCM E26JJ9ZCCM 75 75 3/32 3/32 .156 .156 E26KK7XCCM E26KK9ZCCM Series 20 High Pressure Impact Valves 2 Way Normally Open Explosion Proof - Model EH21 Click here for specs GAS Pressure Rating Orifice Size CV Factor Valve Number LIQUID Pressure Rating Orifice Size CV Factor Valve Number 3000 1/32 .022 EH21G7DCCM 3000 1/32 .022 EH21G7DCCM 2500 3/64 .041 EH21H7DCCMG 1500 3/64 .041 EH21H7DCCML 1350 1/16 .061 EH21J7DCCMG 850 1/16 .061 EH21J7DCCML 450 3/34 .084 EH21K7DCCMG 300 3/32 .084 EH21K7DCCML Series 20 High Pressure Explosion Proof Impact Valves 2 Way Normally Closed 1/4 NPT Stainless Steel - Model EH22 Click here for specs PSI Ratings Gas Orifice Size CV Factor Explosion Proof 1/4 NPT AC DC 3000 3000 1/32 .022 EH22G9DCCM 2500 1500 3/64 .041 EH22H9DCCMG 1750 500 1/16 .065 EH22J9DCCMG 650 100 3/32 .100 EH22K9DCCMG PSI Ratings Liquid Orifice Size CV Factor Explosion Proof 1/4 NPT AC DC 3000 3000 1/32 .022 EH22G9DCCM 1500 1500 3/64 .041 EH22H9DCCML 1000 500 1/16 .065 EH22J9DCCML 300 100 3/32 .100 EH22K9DCCML Series 20 High Pressure Explosion Proof Impact Valves 2 Way Normally Closed 1/8 NPT Stainless Steel - Model EH22 Click here for specs PSI Ratings Gas Orifice Size CV Factor Explosion Proof 1/8 NPT AC DC 3000 3000 1/32 .022 EH22G7DCCM 2500 1500 3/64 .041 EH22H7DCCMG 1750 500 1/16 .065 EH22J7DCCMG 650 100 3/32 .100 EH22K7DCCMG PSI Ratings Liquid Orifice Size CV Factor Explosion Proof 1/8 NPT AC DC 3000 3000 1/32 .022 EH22G7DCCM 1500 1500 3/64 .041 EH22H7DCCML 1000 500 1/16 .065 EH22J7DCCML 300 100 3/32 .100 EH22K7DCCML SERIES 20 High Pressure Explosion Proof Impact Valves 3 Way Normally Closed - Stainless Steel - 1/4 NPT - Model EH23 Click here for specs PSI Ratings Gas Orifice Size CV Factor Explosion Proof AC DC 3000 3000 1/32 .022 EH23GG19DCCM 2500 1500 3/64 .041 EH23HH19DCCMG 1750 500 1/16 .065 EH23JJ19DCCMG 650 100 3/32 .100 EH23KK19DCCMG PSI Ratings Liquid Orifice Size CV Factor Explosion Proof AC DC 3000 3000 1/32 .022 EH23GG19DCCML 1500 1500 3/64 .050 EH23HH19DCCML 1000 500 1/16 .070 EH23JJ19DCCML 300 100 3/32 .130 EH23KK19DCCML Series 50 - Stainless Steel 2 Way Normally Open - Explosion Proof - Model E51 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC Inlet Exh Inlet Exh CONDUIT HOUSING (1/2" NPT) Housing available in all Stainless Steel construction 1/8 NPT Ports 400 200 1/32 .020 E51G8XCCM 200 100 3/64 .048 E51H8XCCM 125 60 1/16 .075 E51J8XCCM 40 40 3/32 .150 E51K8XCCM Series 50 - Stainless Steel 2 Way Normally Closed-Explosion Proof-Model E52 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC Inlet Exh Inlet Exh CONDUIT HOUSING (1/2" NPT) Housing available in all Stainless Steel construction 1/8 NPT Ports 500 250 1/32 .022 E52G8DCCM 400 150 3/64 .055 E52H8DCCM 200 100 1/16 .075 E52J8DCCM 100 45 3/32 .156 E52K8DCCM 75 25 1/8 .230 E52N8DGM Series 50 - Stainless Steel 3 Way Normally Closed Exhaust to Atmosphere-Explosion Proof-Model E53 Click here for specs *Max Oper Press Diff. Orifice Size CV Factor AC DC Inlet Exh Inlet Exh CONDUIT HOUSING (1/2" NPT) Housing available in all Stainless Steel construction 1/8 NPT Ports 200 200 1/32 1/32 .022 .020 E53GG8DCCM 150 150 3/64 3/64 .055 .048 E53HH8DCCM 150 150 3/64 1/16 .055 .075 E53HJ8DCCM 100 100 1/16 1/16 .075 .075 E53JJ8DCCM 60 60 3/32 1/16 .156 .075 E53KJ8DCCM 50 50 3/32 3/32 .150 .150 E53KK8DCCM 30 30 1/8 1/16 .230 .075 E53NJ8DCCM 30 30 1/8 3/32 .230 .150 E53NK8DCCM Series 50 - Stainless Steel 3 Way Normally Closed Piped Exhaust - Explosion Proof - Model E53 Click here for specs *Max. Oper Press Diff. AC DC Orifice Size Inlet Exh CV Factor Inlet Exh CONDUIT HOUSING (1/2" NPT) Housing available in all Stainless Steel construction 1/8 NPT Ports 200 200 1/32 1/32 .022 .020 E53GG8XCCM 150 150 3/64 3/64 .055 .048 E53HH8XCCM 150 150 3/64 1/16 .055 .075 E53HJ8XCCM 100 100 1/16 1/16 .075 .075 E53JJ8XCCM 60 60 3/32 1/16 .156 .075 E53KJ8XCCM 50 50 3/32 3/32 .150 .150 E53KK8XCCM 30 30 1/8 1/16 .230 .075 E53NJ8XCCM 30 30 1/8 3/32 .230 .150 E53NK8XCCM Series 50 - Stainless Steel 3 Way Normally Open - Explosion Proof - Model E54 Click here for specs *Max. Oper Press Diff. AC DC Orifice Size Inlet Exh CV Factor Inlet Exh CONDUIT HOUSING (1/2" NPT) Housing available in all Stainless Steel construction 1/8 NPT Ports 150 150 1/32 1/32 .022 .020 E54GG8XCCM 125 125 3/64 3/64 .048 .055 E54HH8XCCM 100 75 1/16 1/16 .075 .075 E54JJ8XCCM 75 45 1/16 3/32 .075 .156 E54JK8XCCM 50 50 3/32 3/32 .150 .150 E54KK8XCCM 40 25 3/32 1/8 .150 .230 E54KN8XCCM Series 50 - Stainless Steel 3 Way Directional Control - Explosion Proof - Model E55 Click here for specs *Max. Oper Press Diff. AC DC Orifice Size Inlet Exh CV Factor Inlet Exh CONDUIT HOUSING (1/2" NPT) Housing available in all Stainless Steel construction 1/8 NPT Ports 300 200 1/32 1/32 .022 .020 E55GG8XCCM 200 100 3/64 3/64 .055 .048 E55HH8XCCM 100 50 1/16 1/16 .075 .075 E55JJ8XCCM 75 25 3/32 1/16 .156 .075 E55KJ8XCCM 65 20 3/32 3/32 .150 .150 E55KK8XCCM 45 25 1/8 3/32 .230 .150 E55NK8XCCM Series 50 - Stainless Steel 3 Way Multi Purpose - Explosion Proof - Model E56 Click here for specs *Max. Oper Press Diff. AC DC Orifice Size Inlet Exh CV Factor Inlet Exh CONDUIT HOUSING (1/2" NPT) Housing available in all Stainless Steel construction 1/8 NPT Ports 125 125 1/32 1/32 .022 .020 E56GG8DCCM 100 100 3/64 3/64 .055 .048 E56HH8DCCM 65 50 1/16 1/16 .075 .075 E56JJ8DCCM 25 25 3/32 3/32 .150 .150 E56KK8DCCM Series 80, Internal Pilot - Explosion Proof Model E818 - 2 Way Normally Open Click here for specs *Max. Oper Press Diff. Min Oper Press Diff. Orifice Size CV Factor AC DC 1/2" NPT PORTS CONDUIT HOUSING 1/2 NPT GROMMET HOUSING 100 40 0 5/8 4.0 827C12DCV 827G12DGV 150 150 5 5/8 4.0 828C12DCV 828G12DGV 150 150 5 5/8 4.0 818C12DCV 818G12DGV 150 150 5 5/8 4.0 E828C12DCCM N/A 150 150 5 5/8 4.0 E818C12DCCM N/A Series 80, Internal Pilot - Explosion Proof Model E828 - 2 Way Normally Closed Click here for specs *Max. Oper Press Diff. Min Oper Press Diff. Orifice Size CV Factor AC DC 1/2" NPT PORTS CONDUIT HOUSING 1/2 NPT GROMMET HOUSING 100 40 0 5/8 4.0 827C12DCV 827G12DGV 150 150 5 5/8 4.0 828C12DCV 828G12DGV 150 150 5 5/8 4.0 818C12DCV 818G12DGV 150 150 5 5/8 4.0 E828C12DCCM N/A 150 150 5 5/8 4.0 E818C12DCCM N/A
